Description
The Talaria Sting is powered by an impressive 60V 38Ah lithium-ion battery which can be swapped and/or removed in seconds, allowing the possibility of a limitless range with a simple battery swap.
Using electric automobile grade LG 21700 cells combined with state-of-the-art programmed BMS, our torque and efficiency make this bike an outstanding performer on the road or off.
User age: 10 years old and up
CFMOTO recommends that the rider should always wear a helmet, eye protection and other protective clothing.
Image Gallery
Specifications
| Motor Rated Voltage | 60v (DC) |
| Motor Rated Power / Peak Power | 3700W @ 2100rpm |
| Motor Shaft Output Torque | 29.5nm |
| Motor Transmission | Gearbox + Chain |
| Motor Rated Torque / Peak Torque | 8.5nm / 31.8nm |
| Motor Peak Efficiency | 96.6% |
| Motor Type | PMSM |
| Motor Mounting Position | Centre Frame |
| Motor Weight | 7kg |
| Motor External Diameter | 180mm |
| Motor Axial Length | 130mm |
| Motor Cooling Method | Air Cooled |
| Controller Type | FOC |
| Controller Weight | 1.6kg |
| Controller Dimensions (LXWXH) | 240mm x 110mm x 50mm |
| Controller Peak Efficiency | 98.5% |
| Controller Travelling Wave Current | 85A |
| Controller Highest Temperature | 100 °C |
| Powertrain Rated Rotation Speed | 4300 rpm |
| Powertrain Range of Rotation Speed | 0-5300 rpm |
| Powertrain Peak Efficiency | 98% |
| Powertrain Range of Efficiency | 1.4mm – 22.5mm |
| Battery Max Range * | 63 Miles |
| Battery | 60v 38.4A Lithium LG Cells |
| Battery Speedometer | TFT Digital |
| Battery Life Time | 800 Cycles Before |
| Battery Charger | 10A 60V |
| Battery Charging Time ** | 4 Hours |
| Max Load | 100kg |
| Net Weight | 58kg |
| Forks | Manitou (Optional) / RST – DNM |
| Wheel Type | Spoke Wheels 19×1.6 |
| Brakes | 4 Piston Caliper Hydraulic Brakes |
| Chasis Dimensions (LxWxH) | 1870mm x 780mm x 1040mm |
| Chassis – Swing Arm Material | 6061 T4 & T6 Aluminium Alloy |
| Chassis Construction Method | Forged 8000 Tons of Pressure |
| Rear Shock Absorber | Fastace with Linkage |
| Chassis Surface | Anodizing Paint Treated |
| Headlight | LED |
| Minimum Ground Clearance | 270mm |
| Front Tyre Size | 70/100-19 |
| Rear Tyre Size | 80/100-19 |
| Tyres | CST |
| Brake Discs | 203mm |
| Brakes | 4 Piston Caliper Hydraulic Brakes |
| Wheel Type | Spoke Wheels 19×1.6 |
