Description
All-new air-cooled motor with a nominal power of 3.5kW restricted for EU regulations. Donning a 33% increase from the original Sting. Coupled with a notably faster acceleration making the sting R the ideal road going cruiser
User age: 10 years old and up
CFMOTO recommends that the rider should always wear a helmet, eye protection and other protective clothing.
Image Gallery
Specifications
| Motor Rated Voltage | 60v (DC) |
| Motor Rated Power / Peak Power | 4000W |
| Motor Shaft Output Torque | 45nm |
| Motor Transmission | Gearbox + Chain |
| Motor Peak Efficiency | 96.60% |
| Motor Mounting Position | Centre Frame |
| Motor Cooling Method | Air Cooled |
| Controller Type | FOC |
| Controller Peak Efficiency | 92% |
| Battery Max Range * | 52 Miles |
| Battery | 60v 45Ah |
| Battery Speedometer | TFT Digital |
| Battery Charging Time ** | 3 Hours |
| Max Load | 100kg |
| Net Weight | 66kg |
| Forks | Manitou (Optional) / Fastace / Talaria Factory |
| Wheel Type | Spoke Wheels 19×1.6 |
| Chasis Dimensions (LxWxH) | 1880mm x 770mm x 1088mm |
| Chassis Construction Method | Forged 6000 Tons of Pressure |
| Rear Shock Absorber | Talaria Offroad Performance |
| Chassis Surface | Anodizing Paint Treated |
| Headlight | LED |
| Minimum Ground Clearance | 260mm |
| Front Tyre Size | 70/100-19 |
| Rear Tyre Size | 80/100-19 |
| Tyres | CST |
| Wheel Type | Spoke Wheels 19×1.6 |
